Switchcraft - 12B Stereo 1/4" Output Jack Socket

The Switchcraft #12B is an industry-standard open-frame 1/4-inch stereo jack for guitars, basses, pedals and amplifiers. Its tip-ring-sleeve contacts suit stereo wiring and can also be used for battery switching in active instruments.

Specifications

• Connection: 1/4-inch stereo (TRS)
• Contacts: tip, ring and sleeve
• Mounting-hole diameter: 3/8 inch (9.53 mm)
• Bushing thread: 3/8-32
• Threaded bushing length: 1/4 inch (6.35 mm)
• Open-frame construction with solder terminals
• Includes mounting nut and washer
• Manufacturer model: 12B
• Sold individually

Check the control cavity and mounting surface for adequate clearance before installation.
